Brembo 09.8690.11 Brake Disc

$136.40
$136.40

Description

The Brembo 09.8690.11 is a ventilated brake disc with a diameter of 312 mm and a thickness of 25 mm.

Brembo 09.8690.11 Brake Disc
Brembo 09.8690.11 Brake Disc

$136.40

The Brembo 09.8690.11 is a ventilated brake disc with a diameter of 312 mm and a thickness of 25 mm.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
BrandBREMBO
Part number09.8690.11
Part typeDisc Rotor
Diameter Ø312 mm
Thickness (TH)25 mm
Height (A)46 mm
Number of holes (C)5
Centering (B)68 mm
Min. thickness23 mm
Tightening torque120 Nm
Brake disc typeVentilated
AxleFront
Units per box2
Vehicle fitment
  • Audi | A4 B6 Avant | (8E5) | 04/2001-12/2004 | 3.0 quattro 160kW
  • Audi | A4 B6 Avant | (8E5) | 07/2002-12/2004 | 1.8 T 120kW
  • Audi | A4 B6 Avant | (8E5) | 07/2002-12/2004 | 1.8 T quattro 120kW
  • Audi | A4 B6 Avant | (8E5) | 09/2001-07/2002 | 1.8 T 110kW
  • Audi | A4 B6 Avant | (8E5) | 09/2001-07/2002 | 1.8 T quattro 110kW
  • Audi | A4 B6 Avant | (8E5) | 09/2001-12/2004 | 2.0 96kW
  • Audi | A4 B6 Avant | (8E5) | 09/2001-12/2004 | 2.4 120kW
  • Audi | A4 B6 Avant | (8E5) | 09/2001-12/2004 | 2.4 125kW
  • Audi | A4 B6 Avant | (8E5) | 09/2001-12/2004 | 3.0 quattro 162kW
  • Audi | A4 B6 Avant | (8E5) | 11/2002-12/2004 | 1.8 T quattro 140kW
Show all vehicles
  • Audi | A4 B6 Convertible | (8H7) | 04/2002-12/2005 | 2.4 120kW
  • Audi | A4 B6 Convertible | (8H7) | 04/2002-12/2005 | 2.4 125kW
  • Audi | A4 B6 Convertible | (8H7) | 04/2002-12/2005 | 3.0 160kW
  • Audi | A4 B6 Convertible | (8H7) | 04/2002-12/2005 | 3.0 162kW
  • Audi | A4 B6 Convertible | (8H7) | 05/2003-12/2005 | 1.8 T quattro 120kW
  • Audi | A4 B6 Convertible | (8H7) | 05/2003-12/2005 | 3.0 quattro 162kW
  • Audi | A4 B6 Convertible | (8H7) | 07/2002-12/2005 | 1.8 T 120kW
  • Audi | A4 B6 Convertible | (8H7) | 08/2002-12/2005 | 2.5 TDI 120kW
  • Audi | A4 B6 Convertible | (8H7) | 09/2004-12/2005 | 2.0 96kW
  • Audi | A4 B6 | (8E2) | 04/2001-12/2004 | 3.0 160kW
  • Audi | A4 B6 | (8E2) | 04/2001-12/2004 | 3.0 quattro 160kW
  • Audi | A4 B6 | (8E2) | 07/2002-12/2004 | 1.8 T 120kW
  • Audi | A4 B6 | (8E2) | 07/2002-12/2004 | 1.8 T quattro 120kW
  • Audi | A4 B6 | (8E2) | 09/2001-12/2004 | 2.4 120kW
  • Audi | A4 B6 | (8E2) | 09/2001-12/2004 | 2.4 125kW
  • Audi | A4 B6 | (8E2) | 11/2000-07/2002 | 1.8 T 110kW
  • Audi | A4 B6 | (8E2) | 11/2000-07/2002 | 1.8 T quattro 110kW
  • Audi | A4 B6 | (8E2) | 11/2000-12/2004 | 2.0 96kW
  • Audi | A4 B6 | (8E2) | 11/2000-12/2004 | 3.0 162kW
  • Audi | A4 B6 | (8E2) | 11/2000-12/2004 | 3.0 quattro 162kW
  • Audi | A4 B6 | (8E2) | 11/2002-12/2004 | 1.8 T quattro 140kW
  • Audi | A4 B7 Avant | (8ED) | 01/2005-06/2008 | 3.2 FSI quattro 188kW
  • Audi | A4 B7 Avant | (8ED) | 11/2004-06/2008 | 1.8 T 120kW
  • Audi | A4 B7 Avant | (8ED) | 11/2004-06/2008 | 2.0 96kW
  • Audi | A4 B7 Avant | (8ED) | 11/2004-06/2008 | 2.0 TFSI 147kW
  • Audi | A4 B7 Avant | (8ED) | 11/2004-06/2008 | 2.0 TFSI quattro 147kW
  • Audi | A4 B7 Convertible | (8HE) | 01/2006-03/2009 | 1.8 T 120kW
  • Audi | A4 B7 Convertible | (8HE) | 01/2006-03/2009 | 2.0 TDI 103kW
  • Audi | A4 B7 Convertible | (8HE) | 01/2006-03/2009 | 2.0 TFSI 16V 147kW
  • Audi | A4 B7 | (8EC) | 01/2005-06/2008 | 3.2 FSI 188kW
  • Audi | A4 B7 | (8EC) | 01/2005-06/2008 | 3.2 FSI quattro 188kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 1.8 T 120kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 1.8 T quattro 120kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 2.0 96kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 2.0 TDI 103kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 2.0 TDI 16V 103kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 2.0 TFSI 147kW
  • Audi | A4 B7 | (8EC) | 11/2004-06/2008 | 2.0 TFSI quattro 147kW
  • Audi | A6 C5 Avant | (4B5, 4B6) | 08/2001-01/2005 | 3.0 162kW
  • Audi | A6 C5 Avant | (4B5, 4B6) | 08/2001-01/2005 | 3.0 quattro 162kW
  • Audi | A6 C5 Avant | (4B5, 4B6) | 11/1998-01/2005 | 4.2 quattro 220kW
  • Audi | A6 C5 Avant | (4B5, 4B6) | 12/1997-01/2005 | 2.4 121kW
  • Audi | A6 C5 Avant | (4B5, 4B6) | 12/1997-01/2005 | 2.4 quattro 121kW
  • Audi | A6 C5 Avant | (4B5, 4B6) | 12/1997-01/2005 | 2.8 quattro 142kW
  • Audi | A6 C5 | (4B2, 4B4) | 02/1997-01/2005 | 2.4 121kW
  • Audi | A6 C5 | (4B2, 4B4) | 02/1997-01/2005 | 2.4 quattro 121kW
  • Audi | A6 C5 | (4B2, 4B4) | 02/1997-01/2005 | 2.8 142kW
  • Audi | A6 C5 | (4B2, 4B4) | 02/1997-01/2005 | 2.8 quattro 142kW
  • Audi | A6 C5 | (4B2, 4B4) | 06/2001-07/2004 | 3.0 quattro 160kW
  • Audi | A6 C5 | (4B2, 4B4) | 08/2001-01/2005 | 2.4 125kW
  • Audi | A6 C5 | (4B2, 4B4) | 08/2001-01/2005 | 3.0 quattro 162kW
  • Audi | A6 C5 | (4B2, 4B4) | 12/1997-01/2005 | 1.8 T 132kW
  • Skoda | Superb I | (3U4) | 12/2001-03/2008 | 2.8 V6 142kW
  • Volkswagen | Passat B5.5 Variant | (3B6) | 10/2000-05/2005 | 2.8 140kW
  • Volkswagen | Passat B5.5 Variant | (3B6) | 11/2000-05/2005 | 1.8 T 20V 110kW
  • Volkswagen | Passat B5.5 Variant | (3B6) | 11/2000-05/2005 | 1.9 TDI 96kW
  • Volkswagen | Passat B5.5 Variant | (3B6) | 11/2000-05/2005 | 2.3 VR5 125kW
  • Volkswagen | Passat B5.5 | (3B3) | 09/2001-09/2004 | 4.0 W8 4motion 202kW
  • Volkswagen | Passat B5.5 | (3B3) | 10/2000-05/2005 | 2.8 140kW
  • Volkswagen | Passat B5.5 | (3B3) | 11/2000-05/2005 | 1.8 T 20V 110kW
  • Volkswagen | Passat B5.5 | (3B3) | 11/2000-05/2005 | 2.3 V5 125kW
  • Volkswagen | Passat B5.5 | (3B3) | 11/2000-05/2005 | 2.5 TDI 110kW
  • Volkswagen | Passat B5.5 | (3B3) | 11/2000-05/2005 | 2.8 4motion 142kW
BREMBO part number09.8690.11
OE numbersAUDI 3B0615301B, AUDI 4B0615301A, AUDI 8D0615301J, AUDI 8E0615301R, AUDI L8E0615301R, SKODA 4B0615301C
